Location

To create a single line input of type- location, define the type value as location. The list of attributes passed to the input fields are as given below. The mandatory parameters are indicated with a *.

Attribute Name

Data Type

Description

type*


String
Value should be location.

The type of the input field. Value of the field should be location.


placeholder*

String (100)

Sample field value displayed to the user that describes the expected value of the input field.

name*

String (50)

A unique identifier for the form field. Upon submitting a form, the value defined for the key will be available in the function associated with the form.

label*

String (50)

Describes the display name for the field.

hint

String (100)

Provides a brief description of the field's purpose and the expected input.

value

Object

Denotes the latitude and longitude of the selected location. Specifying lat and long coordinates in the value object will display the respective location as selected.

"value": {"latitude": "13.08891","longitude": "80.26483"}

mandatory

Boolean

Defines if the form field is mandatory or not. The default value is false.

boundary

Object

Denotes the latitude and longitude of the location along with the radius. Radius denotes the specific limit within which a location can be selected.
Note: You cannot pick locations falling outside the specified radius.
For example,
"boundary": {"latitude":80.123,"longitude":20.345,"radius":10}

Syntax


{
  "hint": "",
  "name": "",
  "label": "",
  "placeholder": "",
  "type": "location",
  "value": "",
  "mandatory":false ,//boolean,  default is set false
  "boundary":
   {
   "latitude": ,
   "longitude": ,
   "radius":
   }
}



Sample Code


inputs = list();
inputs.add({
"type":"location",
"name":"place",
"label":"Location",
"hint":"Please specify a valid location",
"placeholder":"Click to select location",
"boundary":{
"latitude":41.8781,
"longitude":-87.6298,
"radius":10
},
"mandatory":true
});
form={
"type":"form",
"hint":"Give location access!",
"title":"ZylCal Meetups",
"name":"ID",
"version":1,
"actions":{
"submit":{
"type":"invoke.function",
"name":"userinfo"
}
},
"inputs":inputs
};
return form;
