Date and time

To create a single line input field of the type, date-time - define the value as date_time. The list of attributes passed to the input field type is given below. All the mandatory parameters are indicated with a *

Attribute Name

Data Type

Description
type*


String
Value should be datetime

The type of input field. Value of the date-time field should be datetime


placeholder*

String(100)

Sample field value displayed to the user that describes the expected value of the input field.

name*

String(50)

A unique identifier for the field. Upon form submission, the value defined for the key will be available in the function associated with the form.

label*

String(50)

Describes the display name for the field.

hint

String(100)

Provides a brief description of the field's purpose and the expected input.

value

Object

Describes the date, time and timezone value chosen by the user. You can also specify a default date, time and timezone value as a placeholder.
1.date_time (Mandatory)

2.time_zone_id (Optional)

Expected format of date_time is yyyy-MM-ddTHH:mm:ss
For example:

"value": {
"date_time": "2011-12-03T12:15",
"time_zone_id": "Africa/Lome"
}

mandatory

Boolean

Defines if the form field is mandatory or not. The default value is false.

Syntax


{
  "hint": "",
  "name": "",
  "label": "",
  "placeholder": "",
  "type": "datetime",
  "value": "",
  "mandatory":false //boolean,  default is set false
}

Code sample



inputs = list();
inputs.add({
"type":"datetime",
"name":"DateTime",
"label":"Date and Time Details",
"hint":"Please cite your availability",
"placeholder":"2020-02-03T12:15",
"mandatory":"true",
"value":{
"date_time":"2020-02-03T12:15",
"time_zone_id":"Africa/Lome"
}
});
form = {
"type":"form",
"title":"ZylCal Users",
"name":"ID",
"hint":"Submit your details to get early access to ZylTrix!",
"version":1,
"button_label":"Submit",
"action":{
"type":"invoke.function",
"name":"info"
},
"inputs":inputs
};
return form;
