Single-line Input Type : File Upload

The file upload field in Cliq forms allows you to attach upto a maximum of 10 files. Take a look at the list of attributes passed for this input field type is given below. All mandatory attributes are indicated with a * and the maximum characters allowed is provided with the Data Type.

Attribute NameData Type & LimitDescription
type*string
Value should be file
The type of single line text input field.
placeholder*string (100)Sample field value displayed to the user that describes the expected value of the input field.
name*string (50)A unique identifier for the field. On form submission, the value defined for this key will be available in the function associated with the form.
label*string (50)Describes the field display name.
hint*string (100)Provides a brief description of the field's purpose and the expected input.
mandatorybooleanDefine if the field's requisite is mandatory or not.
Default value considered is true.
multiplebooleanDefine if your field should be a single select or multi select field. For all multi select fields, multiple should be set as true.
max_selectionsinteger
Maximum selections allowed: 10

Defines the number of options that a user can choose from the drop-down.

Note: Value for this field defaults to 1 in case of single select drop-downs.

max_size

integer

Value should be in KB ranging from 1- 51200.

Defines the maximum file size limit for files to be uploaded

Syntax

{
  "hint": "",
  "name": "",
  "label": "",
  "placeholder": "",
  "type": "file",
  "mandatory": true, //boolean, default value is set as true
  "multiple": true, //boolean, default value is set as true
  "max_selections": ""
}

Code Sample

return {
   "type":"form",
   "title":"Event Registration",
   "name":"survey",
   "hint":"Please fill out your details to register for the event",
   "button_label":"Upload",
   "inputs":[
      {
         "label":"Participant Photo",
         "name":"file",
         "placeholder":"Please upload a photo for your runner's ID.",
         "mandatory":true,
         "type":"file"
      }
   ],
   "action":{
      "type":"invoke.function",
      "name":"function"
   }
};
